Owner’s Manual for Portable Generator 7
TABLE 3. Accessories
3. Call Powermate Customer Service at 1-
800-445-1805 with the unit model and
serial number for any missing carton con-
tents.
4. Record model, serial number, and date of
purchase on front cover of this manual.
Assembly
Call Powermate Customer Service at 1-800-
445-1805 for any assembly issues or con-
cerns. Please have model and serial number
available.
The following tools are required to install the
accessory kit.
•See Table 3: Accessories (Tool Kit)
NOTE: The wheels are not intended for over-
the-road use.
See Figure 2-7.
Install wheels as follows:
1. Slide axle pin (3) through wheel (1), M12 x
4mm flat washer (6), and frame.
2. Install M12 x 1.5mm flat washer (7) and
insert cotter pin (12) through axle (4).
Bend tabs (of cotter pins) outward to lock
into place.
Install frame foot assembly as follows:
1. Slide M8 flat washer (8), rubber foot (5),
foot spacer (4) onto M8 x 80 bolt (10).
2. Align through holes in frame rail and
secure with M8 nyloc nut (11).
Install handle as follows:
1. Slide M8 x 50 bolt (9) through handle
bracket and handle (2). Secure with M8
nyloc nut (11).
Item Qty.
Main Unit 1
Owner’s Manual 1
Liter SAE Oil 1
Oil Funnel 1
Wheel (1) 2
Handle (2) 2
Hardware Bag Qty.
Axle Pin (3) 2
Foot Spacer (4) 2
Rubber Feet (5) 2
M12 x 4mm Flat Washer (6) 2
M12 x 1.5mm Flat Washer (7) 2
M8 Flat Washer (8) 2
M8 x 50 Bolt (9) 2
M8 x 80 Bolt (10) 2
M8 Nyloc Nut (11) 4
Cotter Pin (12) 2
Handle Grip (13) 2
Tool Kit Qty.
5mm Hex Key 1
10 x 13mm Wrench 1
Spark Plug Wrench with Rod 1
(000100a)
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
