第 8 页 共 16 页
Mode
Parameter
Default
Rang Comment
0：Soft start only after trimming
1：Soft start after both trimming and stop
07 2 1 ~9 Soft start stitch number
0 8 200 100 ~800 Soft start speed
0 9
20 1 ~20
System accelerate sensitivity （ D i r e c t d r i ve transmission
can be set up to a large value ； belt transmission don't set
large value or too much noise and vibration. This parameter
do not affect the electrical）
0 A 20 1 ~20
System decelerate sensitivity （ D ir e c t d r i v e transmission
can be set up to a large value ； belt transmission don't set
large value or too much noise and vibration. This parameter
do not affect the electrical ）
1 0 1800 200 ~2200
Continuous back tacking speed
1 3 24 0 ~70
Start back tacking stitch compensation 1
1 4 20 0 ~70
Start back tacking stitch compensation 2
1 5 24 0 ~70
End back tracking stitch compensation 1
Back
tacking
setup
1 6 20 0 ~70
End back tracking stitch compensation 2
3 0 0 0 /1 / 2 / 3
Pedal Curve mode setup:
0：Auto Calculated liner Curve（According to the highest speed
automatic computation）
Pedal
3 0 0 0 /1 / 2 / 3
1：Twosegment liner Curve.(You shall be free to set slow start
after fast or fast start after slow,the parameters
“31”and“32”cooperate with use)
Pedal forward angle
speed
S
