3. Installation Instructions
Put the main body on the carpet or cushion as shown
in the picture after taking out from packing carton.
As shown in step(A), open the folding handle in the
direction as shown in the picture. Meanwhile the lower
end of the riser will expand to the two sides naturally.
Raise the riser upward to the upper limit position as
shown in step (B). Press ''folding handle" and lock riser
as shown in step (C).
Fix "phone bracket” with two pieces ST4.2*22 bolts on
riser beam as shown in the step (E) of right picture.
How to Assemble and Fold Handlebars
Hold the left handlebar(F) to the position shown above and insert it to the appropriate position
of the left upright. Tighten them with Screw M10(G) and fix the round plug into the hole on the
left handlebar (H). (Repeat this step on the right handlebar.); After finishing assembling, rotate the
handlebar counter clockwise until it reaches its limit.
Put the "safety lock" into the corresponding position
under the beam of the riser as shown in step (I).
Insert the power cord into the socket of the power
switch and install it.
Note: Please check again whether all bolts are locked after the assembly of the machine
