10
ASSEMBLY
Wheel Kit Installation
1 Install the axle assembly on the generator.
2 Install the two wheels on the axle shaft using the washers and flange nuts.
3 Install the two stands on the under frame using the flange nuts.
Starter Cables Connection
1 Route the starter cable under the tank.
2 Connect the starter cable to the battery positive (
＋
) terminal first, then to the negative (
－
)
terminal. When disconnecting, disconnect at the battery negative (
－
) terminal first.
Battery posts, terminals and related accessories contain lead and lead compounds. Wash hands after
handling.
PRE-OPERATION CHECK
Engine Oil
Engine oil is a major factor affecting engine performance and
service life. Non-detergent and 2-stroke engine oils will damage
the engine and are not recommended.
Check the oil level BEFORE EACH USE with the
generator on a level surface and the engine stopped.
Use 4-stroke motor oil that meets or exceeds the
requirements for API service classification SJ.
