PowerMax XP10000E - SPECIFICATIONS

8
SPECIFICATIONS
Model XP10000E
Frequency 60 HZ
Max.AC Output 10000 Watt
Rated AC Output 8000 Watt
Generator
Run Time 8 hour
Model XP16HPE
Type Air Cooled, OHV, 4-Stroke
Displacement 419 cc
Output 16.0 HP / 3600 rpm
Fuel Unleaded Gasoline
Fuel Tank Capacity 8.3 Gallon
Decibel <71 dBA
Oil Alert Standard
Battery 12V 18A
Engine
Fuel Gauge Standard
Air Cleaner Standard
Silencer Standard
Voltmeter Standard
Voltage Selector Standard
Hour meter Standard
DC Circuit Breaker Standard
DC Receptacle Standard
AC Circuit Breaker Standard
AC Circuit Protector Standard
Standard
Features
AC Receptacle
2 Pole 120V AC
3 Pole 120V/240V AC
Length 34"
Width 27"
Height 32"
Dimensions
Gross Weight 240 lbs.
Receptacle
2 × NEMA 5-20R
1 × NEMA 5-30R
1 × NEMA L14-30R
1 × NEMA 14-50R
Plug(Not included with
your generator)
2 × NEMA 5-20P
1 × NEMA 5-30P
1 × NEMA L14-30P
1 × NEMA 14-50P
