POWERPATH PS-8 - Page 21

P84905-001 A Sheet 21 of 36
□ ■ ■ □ ■ □
AUX Output Current Limit Reduce the number of NAC Appliances on Output1
□ ■ ■ ■ □ □
SYNC BUS Short Check for a wiring short. Check for improperly wired NAC
circuit. (If an appliance is wired + to – and – to + a short trouble
will be indicated.
□ ■ ■ ■ ■ □
SYNC BUS Open Check SYNC BUS terminals for good connections. Check NAC
circuit wiring for continuity. Check NAC circuit for 10K Ohm
EOLR.
■ □ □ □ □ ■
SYNC BUS Current Limit Excessive current on the SYNC BUS. Reduce the number of
Power Supplies connected to the circuit.
■ □ □ □ ■ ■
Dry Contact 1 Ground Fault
(Note 1)
Check for circuit wire to enclosure or conduit.
■ □ □ ■ □ ■
Dry Contact 2 Ground Fault
(Note 1)
Same as above
■ □ □ ■ ■ ■
NAC Output 1+ Ground Fault
(Note 1)
Same as above
■ □ ■ □ □ ■
NAC Output 1– Ground Fault
(Note 1)
Same as above
■ □ ■ □ ■ ■
NAC Output 2+ Ground Fault
(Note 1)
Same as above
■ □ ■ ■ □ ■
NAC Output 2– Ground Fault
(Note 1)
Same as above
■ □ ■ ■ ■ ■
NAC Output 3+ Ground Fault
(Note 1)
Same as above
■ ■ □ □ □ ■
NAC Output 3– Ground Fault
(Note 1)
Same as above
■ ■ □ □ ■ ■
NAC Output 4+ Ground Fault
(Note 1)
Same as above
■ ■ □ ■ □ ■
NAC Output 4– Ground Fault
(Note 1)
Same as above
■ ■ □ ■ ■ ■
AUX Output+ Ground Fault
(Note 1)
Same as above
■ ■ ■ □ □ ■
AUX Output– Ground Fault
(Note 1)
Same as above
■ ■ ■ □ ■ ■
SYNC BUS+ Ground Fault
(Note 1)
Same as above
■ ■ ■ ■ □ ■
SYNC BUS- Ground Fault
(Note 1)
Same as above
■ ■ ■ ■ ■ ■
Battery Wires Ground Fault
(Note 1)
Same as above
Note 1: When LED indicator D3 is lighted, it indicates a general ground fault condition. Momentarily depress switch
SW5 (Ground Fault Detect Enable Pushbutton). The Coded Trouble LEDs will indicate the circuit location of the
ground fault.
FUSE REPLACEMENT PROCEDURE:
1. Turn off the AC Mains Power.
2. Open the enclosure and turn off DC battery power.
3. Remove F1.
4. Replace F1 with a 10A 250V fuse.
5. Remove F2.
6. Replace F2 with a 10A 250V fuse.
7. Turn on DC battery power.
8. Close the enclosure.
9. Turn on AC Mains.
