15 TECHNICAL DATA
Rated voltage
220-240 V
Rated frequency
50 Hz
Rated power
1500W
Rotation speed
5000 min
-1
Blade size
210 x 30 mm
Max. cutting depth
Protection class
Class II
Cable length
Tilting range
-45° / 0° / +45°
Mitre cuts
0° to 45° to the left
Maximum cutting capacity 90°
Maximum cutting capacity 90°-90°
60 x 120 mm
Maximum cutting capacity 45°
Maximum cutting capacity 45°-90°
35 x 120 mm
Maximum cutting capacity 90°-45°
60 x 80 mm
Maximum cutting capacity 45°-45°
35 x 80 mm
Table size
Number of teeth
24 teeth
Weight
9 kg
Laser class
2
Laser wave length
650 nm
Laser output
ss 1 mW
Laser module power supply
2 x 1.5 V Micro (AAA)
16 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
100 dB(A)
Acoustic power level LwA
113 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration):
4.5 m/s²
K = 1.5 m/s²
