PowerShield Centurion Series - Contacting PowerShield; Product Specifications

22
8. Specifications
CAPACITY*
1000 VA / 800 W
1500 VA / 1200 W
2000 VA / 1600 W
3000 VA / 2400 W
INPUT
Voltage
Range
Low Line Transfer
160VAC/140VAC/120VAC/110VAC± 5% or 80VAC/70VAC/60VAC/50 VAC± 5%
( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
Low Line Comeback
175 VAC ± 5 % or 85 VAC ± 5 %
High Line Transfer
300 VAC ± 5 % or 150 VAC ± 5 %
High Line Comeback
290 VAC ± 5 % or 145 VAC ± 5 %
Frequency Range
40Hz ~ 70 Hz
Phase
Single phase with ground
Power Factor
≧ 0.99 @ 220-230 VAC (input voltage)
OUTPUT
Output voltage
Nominal 240Vac Programmable to 208/220/230Vac
AC Voltage Regulation
(Batt. Mode)
± 3%
Frequency Range
(Synchronized Range)
47 ~ 53 Hz or 57 ~ 63 Hz
Frequency Range (Batt. Mode)
50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz
Overload
100%~110%: audible warning
110%-130%: UPS shuts down in 30 seconds at battery mode or transfers to
bypass mode when the utility is normal.
>130%: UPS shuts down immediately at battery mode or transfer to bypass
mode when the utility is normal.
Current Crest Ratio
3:1
Harmonic Distortion
≦ 3 % THD (Linear Load)
≦ 6 % THD (Non-linear Load)
≦ 4 % THD (Linear Load)
≦ 7 % THD (Non-linear Load)
Transfer
Time
AC Mode to Batt. Mode
Zero
Inverter to Bypass
4 ms (Typical)
Waveform (Batt. Mode)
Pure Sinewave
EFFICIENCY
AC Mode
~ 85%
~ 88%
Battery Mode
~ 83%
BATTERY
Standard
Model
Battery Type
12 V / 9 AH
12 V / 9 AH
12 V / 9 AH
12 V / 9 AH
Numbers
3
3
6
6
Recharge Time
4 hours recover to 90% capacity (Typical)
Charging Current
1.0 A(max.)
Charging Voltage
41.0 VDC ± 1%
82.1 VDC ± 1%
Long-run
Model
Battery Type &
Numbers
Depending on the capacity of external batteries
Charging Current
8.0 A(max.)
Charging Voltage
41.0 VDC ± 1%
82.1 VDC ± 1%
PHYSICAL
Tower
Case
Dimension, D X W X H
397 X 145 X 220 (mm)
421 X 190 X 318 (mm)
Net Weight (kgs)
13
7
14
7
26
13
28
13
Rack
Case
Dimension, D X W X H
420x438x88[2U] (mm)
580x438x133[3U] (mm)
Net Weight (kgs)
16
10
17
10
29
17
31
17
ENVIRONMENT
Operation Humidity
20-90 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 45dBA @ 1 Meter
MANAGEMENT
RS-232 or USB
Supports Windows® 2000/2003/XP/Vista/2008, Linux, Unix and MAC
Optional SNMP
Power management from SNMP manager and web browser
* Derate capacity to 60% of capacity in Frequency converter mode and to 80% when the output voltage is adjusted to
208VAC.
**Product specifications are subject to change without further notice.
