KNOWING YOUR LAWN MOWER
Please use the illustration below to familiarize yourself with the location and function of the components
that control of your lawn mower.
1 Recoil starter handle 7 Cutting height adjustment lever
2 Cutting height adjustment lever 8 Primer bulb
3 Rear wheel 9 Gas tank cap
4 Side discharge chute 10 Lower handle
5 Oil dipstick 11 Upper handle
6 Front wheel 12 Engine start/stop lever
12 11 10 9
4 5 6 7
8
1
2
3
