23
E02-2 90682-Z030320-0000 SEAL, OIL 1 E10-2 19352-Z2P0110-00A0 IMPELLER 1
E02-3 90001-0630-01 BOLT 7 E10-3 28020-Z2P0110-0000
SEAT,
STARTER CUP
1
E02-4 16400-Z2P0111-00A0
GEAR ASSY,
GOVERNOR
1 E10-4 13510-Z2P0110-00A0
FLYWHEEL
SUBASSEMBLY
1
E02-5 16013-Z030120-0000
PLATE,
GOVERNOR
SPINDLE
COMPRESSION
1 E10-5 30029-Z2P0110-0000 LUG， SHROUD 1
E02-6 90001-0616-01 BOLT 1 E10-6 90007-0516-A1 BOLT 1
E02-7 90502-0812-00 PIN 2 E10-7 45200-Z2P0110-JS00 BRAKE ASSY. 1
E03-1 14081-Z2P0110-00A0 TAPPET, VALVE 2 E10-8 90007-0520-A1 BOLT 3
E03-2 14071-Z2P0110-00A0 LIFTER, VALVE 2 E10-9 30400-Z2P0110-0000
COIL,
IGNITION
1
E03-3 12131-Z3C0110-00A0
GASKET,
CYLINDER
HEAD
1 F01-1 17001-Z2P0110-00A0
GASKET, AIR
CLEANER
1
E03-4 12140-Z3C0110-00A0
HEAD
SUBASSEMBLY,
CYLINDER
1 F01-2 17100-Z2P0110-0000 CLEANER, AIR 1
E03-5 90001-0850-01 BOLT 4 F01-3 90305-0600-31 NUT 2
E03-6 30010-Z120110-00A0 PLUG, SPARK 1 F01-4 17004-Z2P0110-0000
TUBE,
BREATHER
1
E03-7 12101-Z810210-00A0 GUIDE, SEAL 1 F02-1 90107-0413-03 BOLT 3
E03-8 12110-Z3C0110-00A0 VALVES SET 2 F02-2 18130-Z2P0210-0000
COVER,
MUFFLER
OUTER
1
E03-9 12103-Z030110-0000 SPRING, VALVE 2 F02-3 90001-0616-01 BOLT 2
E03-10 12112-Z010110-00A0
SEAT, VALVE
SPRING
2 F02-4 18100-Z2P0210-0000
MUFFLER
ASSY.
1
E03-11 14310-Z2P0110-00A0
ROCKER
SUBASSEMBLY,
VALVE
2 F02-5 18020-Z2P0110-00A0
PLATE,
MUFFLER
INSULATOR
1
E03-12 14330-Z2P0110-00A0
SHAFT, VALVE
ROCKER
1 F03-1 16600-Z2P0110-Q2A9
TANK ASSY,
FUEL
1
E03-13 12411-Z2P0110-0000
COVER,
CYLINDER
HEAD
1 F03-2 16744-Z620120-0000
TANK CAP
CHAIN
1
E03-14 90007-0512-A1 BOLT 4 F03-3 16730-Z620210-LKD0
COVER, FUEL
TANK
1
E04-1 13300-Z3C0910-00A0
CRANKSHAFT
ASSY.
1 F03-4 16652-Z030110-00A0
STRAINER，
FUEL
1
E04-2 14014-Z2P0210-00A0
GEAR, TIMING
DRIVE
1 F03-5 90685-1000-01 CLAMP 1
