34
Item Stock# Description Qty Item Stock# Description Qty
1 303020245 Hex Flange Bolt M8X14 6 29 303020332 Bolt M8×14 4
2 303070234 Bearing Block 2 30 303181158 Impeller 1
3 203060013 Plastic Bearing 2 31 303030032 Lock Nut M6 2
4 203060012 Auger Sleeve 8 32 303020442 Hex Washer Bolt φ6×35 2
5 303180409 Right Auger Welding 2 33 303020166 Bolt M8×18 4
6 203050108 Spacer Bush 1 4 34 303070197 Skid Shoes 2
7 203050109 Spacer Bush 2 8 35 303030077 Flang Lock Nut M8 4
8 302130005 Skeleton seal φ19×φ32×7 2 36 303181159 Auger Housing Welding 1
9 303090032 Worm gear Box Left 1 37 203050511 Lower chute seat 1
10 303060055 Worm Gear Shaft Sleeve 2 38 303020341 Bolt M6×16 4
11 303090033 Worm Gear 1 39 303030087 Flange Lock Nut M6 4
12 303110022 Woodruff Key 1 40 303160192 Small Tensioning Plate Spacer 1
13 303070260 Worm Gear Shaft Sleeve 1 41 303020154 Bolt M8×40 1
14 303090031 Worm gear Box Right 1 42 303071345 Big Tension Plate 1
15 303020142 Bolt M8x10 2 43 303160195A Tensioning Wheel Casing 1
16 303020489 M6×18 6 44 203100003 Tensioning Wheel Assembly 1
17 303160370 Auger Axle 1 45 303030077 Flange Lock Nut M8 1
18 303100030
Deep groove ball bearing
6001Z
1 46 303030059 Lock Nut M10 1
19 303100035
Deep groove ball bearing
6904Z
1 47 303042078 Flat Washer φ10×φ30×2 3
20 303070179 Worm Box Washer 1 48 303160175
Large Tensioning Plate Tension
Spring
1
21 303100039 Bearing 51104 1 49 303100040 Bearing 1
22 302130002 Skeleton seal φ20×φ35×7 1 50 303070233 Bearing Plate 1
23 303160314 Worm 1 51 303030077 Flang M8 3
24 303160355 Shear Pin 4 52 303160794A 7109 Big Pulley 1
25 303180410 Auger Welding Left 2 53 303110014 Flat Key C6X18 1
26 303030032 Lock Nut M6 4 54 303042005 Flat Washer φ8×φ28×3 1
27 303030076 Flang Normal Nut M8 4 55 303020279 Hex Washer M8×20 1
28 303071330 24" Shave 1 56 302040079 V-Belt 720mm,4LXA 1
