DigiMod 500 1000 1500 2000HV 1000NPS | SERVICE MANUAL
INDEX
9. SIlpad Replacement Procedure
IS000040 ULTRASOFT 18x30 mm
IS000031 HI-FLOW 40x55 mm
Once the repair procedure has been ultimated, replace all silpads.
Remove any residue of dirt, glue or dust that might have been
trapped in the module.
The following images portray where to place the IS000040 Silpad.
DigiMod 1000NPS DigiMod 500, 1000, 1500, 2000HV
When replacing the IS000031 SilPad, clean all the components
and the heatsink prior to tightening te retainer springs in place.
