Specifications
DigiMod 500/1000/1500/2000HV/1000NPS
SPECIFICATIONS
GENERAL
Type .......................................................................................... high efficiency 1/2 channels amplifier for professional applications
POWER REQUIREMENTS
DigiMod1000 / (DigiMod500)
230Vrms mains voltage selection ............................................... AC 230+/ - 10 % 50/60 Hz / 1.6 (1.0) A
115Vrms mains voltage selection ............................................... AC 115+/ - 10 % 50/60 Hz / 2.6 (2.0) A
DigiMod1500
230Vrms mains voltage selection ............................................... AC 230+/ - 10 % 50/60 Hz / 2.2 A
115Vrms mains voltage selection ............................................... AC 115+/ - 10 % 50/60 Hz / 3.6 A
DigiMod2000HV
230Vrms mains voltage selection ............................................... AC 230+/ - 10 % 50/60 Hz / 2.9 A
115Vrms mains voltage selection ............................................... AC 115+/ - 10 % 50/60 Hz / 5.5 A
DigiMod500+DigiMod1000NPS/ DigiMod1000+DigiMod1000NPS
230Vrms mains voltage selection ............................................... AC 230+/ - 10 % 50/60 Hz / 2.2 A
115Vrms mains voltage selection ............................................... AC 115+/ - 10 % 50/60 Hz / 3.6 A
POWER REQUIREMENTS DigiMod1000NPS
Power bus .................................................................................. Dc +/- 75 V (+8% -20%)@(7 A)
Auxiliary supply
........................................................................... Dc +15V (+30% -15%)@(0.7 A) / -15 V (+30% -15%)@ (0.3 A)
+7V (+30% -15%)@(0.5 A)
All requirements are provided by a master DigiMod 500 orDigiMod 1000 thru slave connector
DIMENSIONS / WEIGHTS
Weight ........................................................................................ 1.0 Kg DigiMod500
Weight ........................................................................................ 1.1 Kg DigiMod1000
Weight ........................................................................................ 1.15 Kg DigiMod1500/2000HV
Weight ........................................................................................ 0.6 Kg DigiMod1000NPS
External dimensions ................................................................... 216mm (W), 122mm (D), 51mm (H) DigiMod500/1000/1500
External dimensions ................................................................... 146mm (W), 122mm (D), 51mm (H) DigiMod1000NPS
AUDIO SECTION
Slew Rate (8Ω) ....................................... 50V/Us Gain (Digimod500/1000/1500/1000NPS) ....... 32 dB
S/N ratio ................................................. 105 dB/A Gain (Digimod2000HV) .................................. 38 dB
Distortion ................................................ <0.5% (THD, DIM, SMPTE) Output ............................................................ Unbalanced to ground
Inputs...................................................... Balanced to ground Bandwidth ...................................................... 10 Hz - 30KHz
Impedance.............................................. 10 KΩ
Damping factor 500Hz/8Ω (Digimod500/1000/1500/1000NPS) ................ > 500
Damping factor 500Hz/8Ω (Digimod2000HV) ........................................... > 100
POWER SPECIFICATIONS (measured at 115 or 230V AC, 50/60Hz)
DigiMod500 DigiMod500+DigiMod1000NPS
Power continuous Power continuous, all channels driven
(1KHz, 0.5% THD) 4Ω = 450W 8Ω = 260W (1KHz, 0.5% THD) 4Ω = 3X 350W 8Ω = 3X 230W
Power EIAJ Power EIAJ, all channels driven
(1KHz, 1% THD) 4Ω = 530W 8Ω = 280W (1KHz, 1% THD) 4Ω = 3X 410W 8Ω = 3X 250W
DigiMod1000 DigiMod1000+DigiMod1000NPS
Power continuous, both channels driven Power continuous, all channel driven
(1KHz, 0.5% THD) 4Ω = 2X 390W 8Ω = 2X 240W (1KHz, 0.5% THD) 4Ω = 4X 310W 8Ω = 4X 210W
Power EIAJ, both channels driven Power EIAJ, all channels driven
(1KHz, 1% THD) 4Ω = 2X 500W 8Ω = 2X 270W (1KHz, 1% THD) 4Ω = 4X 375W 8Ω = 4X 230W
Bridged 8Ω = 1000W 16Ω = 520 W Bridged 8Ω = 2X 750W 16Ω = 2X 460W
DigiMod1500 DigiMod2000HV
Power continuous, both channels driven Power continuous, both channels driven
(1KHz, 0.5% THD) 4Ω = 2X 590W 8Ω = 2X 330W (1KHz, 0.5% THD) 8Ω = 2X 780W 16Ω = 2X 440W
Power EIAJ, both channels driven Power EIAJ, both channels driven
(1KHz, 1% THD) 4Ω = 2X 750W 8Ω = 2X 370W (1KHz, 1% THD) 8Ω = 2X 1050W 16Ω = 2X 570W
Bridged 8Ω = 1500W 16Ω = 740W Bridged 16Ω = 2100W 32Ω = 1140W
FUNCTIONS
• Thermal protection (over-temperature power limiting, thermal shutdown)
• Short-circuit / overload output protection
• Clip limiter, Permanent signal limiter, High frequency protection
• Auxiliary output voltage (±12V regulated , 200mA )
• Bypass outputs for external active/passive filters
• Digimod500/1000/1000NPS: Temperature controlled Fan output (CN10)
• Digimod1500/2000HV: Temperature controlled Fan
• DSP based or Analog processing plugin optional boards
