DGMDSPA installation
DigiMod 500/1000/1500/2000HV/1000NPS
DGMDSPA installation consist in removing J3 and J4 jumpers to allow signal path to flow to
DGMDSPA board or remove the jumpers located on pins 3,4 of CN18 and 1,2 of CN17 ( in the
latest releases of the units) .
Insert the DGMDSPA board on the only one spare simm socket on the main board of DigiMod
module. Take care that side holders are correctly closed and the polarization is respected.
The module is ready to work.
