powersoft DigiMod 2000HV User Manual

07/11/07 Powersoft s.r.l. - P. IVA n. 04644200489 – Via E.Conti, 5 Scandicci - Tel.: (+39) 055 7350230- Fax: 055 7356235
6
Mating connectors
DigiMod 500/1000/1500/2000HV/1000NPS
Connectors ID Manufacturer Model/Code
CN1 (2POLES 7.5mm) Phoenix Contact GMSTB 2,5/2-ST(Cod. Ph.C. 1766880)
(DigiMod500/1000/1500) (Cod. Powersoft CN000153)
CN1 (2 poles, Faston) Various 6.3x0.8 mm female Faston
(DigiMod2000HV)
CN2 (2POLES 7.5mm) Phoenix Contact GMSTB 2,5/2-ST (Cod. Ph.C. 1766880)
(DigiMod500/1000/1500) (Cod. Powersoft CN000153)
CN2 (2 poles, Faston) Various 6.3x0.8 mm female Faston
(DigiMod2000HV)
CN3 (2POLES 5.08mm) Phoenix Contact MSTB 2,5/2-ST-5,08 (Cod. Ph.C. 1757019)
(DigiMod500/1000/1500) (Cod. Powersoft CN000149)
CN3 (2 poles, Faston) Various 4.8x0.8 mm female Faston
(DigiMod2000HV)
CN7 (2POLES 5.08mm) Phoenix Contact MSTB 2,5/2-ST-5,08 (Cod. Ph.C. 1757019)
(DigiMod500/1000/1500) (Cod. Powersoft CN000149)
CN7 (2 poles, Faston) Various 4.8x0.8 mm female Faston
(DigiMod2000HV)
CN14 (4POLES 5.08mm) Phoenix Contact MSTB 2,5/4-ST-5,08 (Cod. Ph.C. 1757035)
(Cod. Powersoft CN000151)
CN11 (5POLES 5.08mm) Phoenix Contact MSTB 2,5/5-ST-5,08 (Cod. Ph.C. 1757048)
(Cod. Powersoft CN000152)
CN12 (5POLES 5.08mm) Phoenix Contact MSTB 2,5/5-ST-5,08 (Cod. Ph.C. 1757048)
(Cod. Powersoft CN000152)
CN10 (3POLES 2.54mm) Molex22-01-2035 (Molex ordering number )
CN15 (10POLES 3.0mm) Molex 43025-1000 (Molex Housing ordering number)
43030-0001 (Molex contact ordering number )
CN8 (72POLES Simm socket) Various Right polarized / 1,27mm Pcb thickness
CN16 (8 POLES 2.54mm) Berg DUBOX (Cod. Ph.C. 76384-308)
(Cod. Powersoft CN000218)
CN17 (4 POLES 2.54mm) Berg DUBOX (Cod. Ph.C. 76384-304)
(Cod. Powersoft CN000217)
CN18 (4 POLES 2.54mm) Berg DUBOX (Cod. Ph.C. 76384-304)
(Cod. Powersoft CN000217)
