Dedicated 36 VDC Trolling Motor Battery Configuration with (3) 12 VDC Batteries
Connected with (2) Series Jumpers
Installation
When connecting each jacketed battery charger cable, make sure it is connected
to only one 12 VDC battery and observe the polarity and color of all connections:
• Red Wire to the “+” (Positive) Battery connection
• Black Wire to the “-” (Negative) Battery connection
The black wire can never be connected to a terminal with red wires and vice
versa.
Important: The pair of red and black wires in 1 cable jacket MUST GO TO
THE SAME 12VDC battery.
Fig. 3 Three Bank Charger for three 12V Batteries
3 Bank Charger
Typical Wiring
b. DC CONNECTION PRECAUTIONS
CAUTION
IMPORTANT NOTICE: C-Tick
Connect and disconnect the DC output cables only after removing AC cord from
an electric outlet. Never allow the cables to touch each other.
Your Battery Charger has been designed and tested to comply with C-Tick .
These regulations are to provide adequate protection against harmful interfer-
ence while operated in a commercial application. If in a residential setting, you
are encountering interference with TV and radio reception, simply remove AC
power from the unit to confirm if your battery charger is causing interference.
End user can explore the following to minimize interference:
1) Choose a different AC circuit to power on your battery charger.
2) Make sure your outlet is properly grounded.
3) Re-position receiving antenna.
4) Purchase a separate AC line filter.
5) Place the charger to the furthest point from the home wireless equipment,
TV,radio, etc.
