INSTRUCTIONS PL300E/PL400E/PL500E/PL800E SLIDING GATE OPENER USER MANUAL
1) Warnings
Please read this instruction manual carefully before the installation of
gate-automated system.
This manual is exclusively for qualified installation personnel. The
manufacturer is not responsible for improper installation and failure to
comply with local electrical and building regulations.
Keep all the components of PL300E / PL400E / PL500E / PL800E system
and this manual for further consultation.
In this manual, please pay extra attention to the
contents marked by the symbol:
● Be aware of the hazards that may exist in the procedures of installation
and operation of the gate-automated system. Besides, the installation
must be carried out in conformity with local standards and regulations.
● If the system is correctly installed and used following all the standards
and regulations, it will ensure a high degree of safety.
● Make sure that the gates works properly before installing the
gate-automated system and confirm the gates are appropriate for the
application.
● Do not let children operate or play with the gate-automated system.
● Do not cross the path of the gate-automated system when operating.
● Please keep all the control devices and any other pulse generator away
from children to avoid the gate-automated system being activated
accidentally.
● Do not make any modifications to any components except that it is
mentioned in this manual.
● Do not try to manually open or close the gates before you release the
gear motor.
● If there is a failure that cannot be solved and is not mentioned in this
manual, please contact qualified installation personnel.
● Do not use the gate-automated system before all the procedures and
instructions have been carried out and thoroughly read.
● Test the gate-automated system weekly and have qualified installation
personnel to check and maintain the system at least every 6-month.
● Install warning signs (if necessary) on the both sides of the gate to warn
the people in the area of potential hazards.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision. The instructions shall state the substance of the following:
WARNING: Important safety instructions. It is important for the safety of
persons to follow these instructions. Save these instructions.
The instructions shall include the substance of the following:
– do not allow children to play with fixed controls. Keep remote controls away
from children;
– explanation of mode indicators;
– details on how to use any manual release, and if applicable, state that
activation of the manual release may cause uncontrolled movement of the
driven part due to mechanical failures or an out-of-balance condition;
– when operating a biased-off switch, make sure that other persons are
kept away;
– when closing a window that has been opened by a fire-sensing system, make
sure that other persons are kept away;
– frequently examine the installation for imbalance and signs of wear or
damage to cables, springs and mounting. Do not use if repair or adjustment is
necessary;
– disconnect the supply when cleaning or other maintenance is being carried
out, if the appliance is automatically controlled.
The installation instructions shall state the substance of the following:
WARNING: Important safety instructions. Follow all instructions since incorrect
installation can lead to severe injury.
The installation instructions shall specify the type, size and mass of the driven
part, and locations where the drive can be
installed. They shall state that the installer is to check that the temperature
range marked on the drive is suitable for the
location.
The installation instructions shall include the substance of the following:
– the necessary information for safe handling of a drive weighing more than
20 kg. This information shall describe how to use the handling means, such
as hooks and ropes;
– before installing the drive, check that the driven part is in good mechanical
condition, correctly balanced and opens and closes properly;
– information if the drive is intended to be installed at a height of at least 2,5 m
above floor level or other access level;
– that the drive cannot be used with a driven part incorporating a wicket door
(unless the drive cannot be operated with the wicket door open);
– ensure that entrapment between the driven part and the surrounding fixed
parts due to the opening movement of the
driven part is avoided;
– details for the installation of the drive and its associated components,
including any noninherent protection devices or deformable edges;
– that the actuating member of a biased-off switch is to be located within direct
sight of the driven part but away from moving parts. Unless it is key operated,
it is to be installed at a minimum height of 1,5 m and not accessible to the
public;
– that windows, having a gap exceeding 200 mm when open, are to be closed
using a biased-off switch if the opening movement is controlled by a
fire-sensing system;
– details on how to set controls;
– after installation, ensure that the mechanism is properly adjusted and that the
protection system and any manual release function correctly;
– permanently fix the label concerning the manual release adjacent to its
actuating member.
Rohs Warnings
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.
