PowerTech PL800E User Manual

2.1 Standard Installation Demonstration
1. 24V DC sliding motor
2. Transmitter
3. Safety photo sensor
4. Flashing light
a. Operation gear
b. Limit switch device
c. 24Vdc motor
d. Back-up batteries (Optional)
e. Release device
f. Control panel
g. Terminals of devices
h. Green Box (Optional)
2. Installation:
3
4
2
3
e
h
f
g
a
b
c
d
2.2 Description of Device
INSTRUCTIONS PL300E/PL400E/PL500E/PL800E SLIDING GATE OPENER USER MANUAL
3
1

PowerTech PL800E Specifications

General

Brand	PowerTech
Model	PL800E
Category	Gate Opener
Language	English
