Powerware 3110 - Page 8

Installation
4
Powerware
®
3110 User's Guide  05147486 B (English) Uncontrolled Copy
Fault Indicator
Output Receptacles
(Battery and Surge Protection)
Output Receptacles
(Surge Protection Only)
Power Indicator
Figure 2. 230V Model Top Panel
Circuit Breaker Power Cord
Network Transient Protector
Communication Port
On/Standby Switch
Figure 3. 120V Model Side Panel (600 VA Shown)
Circuit Breaker Input Connector
Network Transient Protector
Communication Port
On/Standby Switch
Figure 4. 230V Model Side Panel (600 VA Shown)
