A --- 2
Po werware 9315 P arallel Redundant System I & O
164202013, Rev. D 041599
OUTPUT
NEUTRAL
CONNECTION
(E12)
TB3
TERMINAL STRIP
AC OUTPUT
(E9, E10, E11)
RIGHT SIDE PANEL
LEVELING FEET
SIDE PANEL
MOUNTING SCREWS
LEFT SIDE PANEL
LEFT DOOR
COMMUNICATION
PANEL
NOTE: 100---160 KVA UPS Shown with Right Door Open or Removed
TB3
TB1
TB2
Figure 11. UPS Outputs and Communications
