Dimensions
165mm
160mm
85mm
Electricity supply 230V 50Hz Fused at 6A.
Internal Fuses F1 20mm 6.3A 230V.(HRC), F2 20mm 500mA 230V. (Non replaceable)
Display 2 line 5mm Backlit L.C.D.
Day set point range 10 - 60°C.
Night set point range 1 - 15°C.
Temperature accuracy 0.5 °C.
Overall switching dierential Adjustable 0.5 - 10.0°C for Hi/Lo burner types.
Sensing Element Internal or remotely mounted up to 100m from control.
Switching contacts ratings 12A. 230V.ac. (resistive). All Volt Free
Modulating Control 0-10V dc
Heating ON Indicator
Green L.E.D. when the heater is a single-stage burner,
Red when the burner is a Hi-Low type,
Yellow when the burner is a Modulating type.
Fault (Lockout) Indicator Orange L.E.D.
Protection Rating IP20
Software versions G
1.2 Technical Data
