Powrmatic MC200/V3 User Manual

page no. 20 of 24
MC200/V3 Users, Installation & Servicing Instructions Doc Ref M401 issue 5.4 Feb 2018.
Trim temp +0.0
.
C
A temperature oset can be entered here to adjust
the displayed temperature to agree with the sensor
temperature. (Default: 0.0°C)
Range of adjustment: -5°C to +5°C
your setting here
UserTempMin 15
.
0
Sets the minimum temperature that the User can select.
(Default: 15°C)
Range of adjustment: 10°C - 20°C.
your setting here
UserTempMax 30
.
0
Sets the maximum temperature that the user can select.
(Default: 30°C)
Range of adjustment: 20°C - 60°C.
your setting here
Temp adjust 3
.
0
Sets °C that User can temporarily adjust the current set
point up or down. (Default: 3°C), Range is 0.5°C to 30°C.
your setting here
ConstFan: Off
Sets the mode of Fan operation between:
OFF: For Summer operation - fan only operates when Fan
button is pressed and will remain on until Fan button is
pressed again or until midnight,
Auto: fan runs at dictate of fan thermostat on heater),
Const: fan runs continuously when timer is in Heat On
state, or
ON: fan runs 24/7. (Default: OFF)
your setting here
ModOffset 6.0
.
C
*Note: This menu item only appears when Modulation burner
type has been selected.
Sets the temperature at which the 0-10V signal will be 10V
and the burner will be at High Fire. (Default: 6°C)
Range of adjustment: 3.0°C to 30.0°C
your setting here
Auto reset OFF
Sets whether the control will complete an automatic reset
of lockout, If lockout signal is not removed by a manual
reset the MC200 will initiate an automatic reset 30 minutes
after the lockout signal and then once every 24hrs.
(Default: OFF)
Options - ON, OFF
your setting here
Reset time 1 sec
Sets how long the lockout reset terminal is connected to
neutral when the reset button is pressed. (Default: 1 second)
Options: 1 second, 3 seconds, 5 seconds)
your setting here
Snsr2: Not used
Sets the function of sensor 2 input (alos known as IN2).
(Default: Not used)
Options: Not Used, Remote, Close = o, Close = on, Open =
o, Open = on
Not used: The sensor 2 terminals are ignored
Remote: A temperature sensor is connected
Close = o A switch is tted. When it closes, heating
goes o
Close = on A switch is tted. When it closes, heating
goes on
Open = o A switch is tted. When it opens, heating
goes o
Open = on A switch is tted. When it opens, heating
goes on
your setting here
