Installation Instructions
Surface mounting
Magnetic base
5
• Clean the entire surface on which you plan to place
the antenna.
• Remove nut, foam seal and Short spigot from
antenna.
• Secure the magnetic base to the antenna with at
head screws.
• Place antenna onto magnetic surface.
• Route the cable as required.
Magnetic surface for Optional
Magnet Base kit installation
• Clean the entire surface on which you plan to stick
the antenna.
• Remove nut, foam seal and Short spigot from
antenna.
• Secure the magnetic base to the antenna with at
head screws.
• Peel off the wax paper layer and stick the foam
seal to the magnetic base.
• Peel off the second wax paper layer and rmly
press the antenna down onto the surface.
• Route the cable as required.
Adhesive mounting
