PPI neuro 102 - Universal Single Loop Process Controller; Table of Contents

CONTENTS
User Manual
neuro 102
1. FRONT PANEL LAYOUT 1
2. BASIC OPERATION 3
3. SET-UP MODE ACCESS AND OPERATION 8
4. 10CONTROL PARAMETERS
5. ALARM PARAMETERS 12
6. CONFIGURATION PARAMETERS 14
7. SUPERVISORY PARAMETERS 17
8. 19PROFILE PARAMETERS
9. OP2 & OP3 FUNCTION PARAMETERS 22
10. HARDWARE ASSEMBLY & CONFIGURATIONS 24
11. MECHANICAL INSTALLATION 31
12. ELECTRICAL CONNECTIONS 33
For Size 48X48
For Size 96X96
1. FRONT PANEL LAYOUT 38
2. HARDWARE ASSEMBLY & CONFIGURATION 40
3. 44ELECTRICAL CONNECTIONS
