< 3.5 mm
> 24 mm
35 mm
3000V101-UK 7
INSTALLATION ON DIN RAIL
To avoid short circuit between the power rail connectors on the 3111, 3112
and 3113 devices and the screws holding the 7.5 mm DIN rail, the head
of the screws shall be no more than 3.5 mm high.
MODULE STOP
3000 units must be supported
by module stops for marine
applications.
Module stop
- PR part number 9404 -
