PR electronics 3101 Product Manual

12 3000V103-UK
Order codes
Accessories
9404 = Module stop for rail
Accessories for power rail devices
3405 = Power rail connector unit
9400 = Power rail - 7.5 or 15 mm high
9410 = Power control unit
9421 = Power supply
Technical data
Environmental conditions:
Operating temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -25°C to +70°C
Storage temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40°C to +85°C
Calibration temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20...28°C
Relative humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 95% RH (non-cond.)
Protection degree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IP20
Installation in pollution degree 2 & overvoltage category II.
Mechanical specifications:
Dimensions (HxWxD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113 x 6.1 x 115 mm
Weight approx. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 g
DIN rail type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DIN EN 60715 - 35 mm
Wire size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.13...2.5 mm
2
/ AWG 26...12 stranded wire
Screw terminal torque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 Nm
Vibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 60068-2-6
2...25 Hz. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±1,6 mm
25...100 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±4 g
Input Output
LED Supply Isolated HART
TC Pt100 Current
Volt age
J & K Int. CJC
Ext.
CJC
2-, 3-,
4-wire
Active Passive
3101
    
24 VDC
3102
   
24 VDC
3111
     
24 VDC /
power rail
2.5 kV
3111-N
     
24 VDC 2.5 kV
3112
   
24 VDC /
power rail
2.5 kV
3112-N
   
24 VDC 2.5 kV
3113
     
24 VDC /
power rail
2.5 kV

3113-N
     
24 VDC 2.5 kV

3331
    
Loop-powered 2.5 kV
3333
 
Loop-powered
3337
    
Loop-powered 2.5 kV

