12 9202- Product version 9202-003
Configuration of cable fault check
Diagnostics
Cable fault detection
Hardware / software error
Cable fault check, independent detection and visualisation for each channel:
Device: Configuration, common for both channels Cable fault detection:
9202
CA.BR = Yes or CA.SH = Yes OFF
Else: ON
Cable fault detection (CA.BR, CA.SH):
Input Event Readout Limit
All Cable break CA.BR < 0.1 mA
All Short-circuited cable CA.SH > 6.5 mA
Readout at hardware error
Error search Readout Cause
Communications test 45xx and 9202 NO.CO Connection error
EEprom error - check configuration FL.ER
Configuration error or crc mismatch,
recovery configuration is loaded
Hardware error DE.ER Invalid recovery configuration in device
Hardware error FC.ER Invalid code checksum in 45xx
EEprom error - check configuration CO.ER Invalid configuration (CRC or data)
Hardware error CA.ER Factory calibration error
Hardware error HW.ER HW setup - configuration mismatch
Hardware error OC.ER Main output controller communication error
Hardware error MS.ER Main internal supply out of bounds
Hardware error MI.ER Main initialisation selftest failed
Hardware error MC.ER Main flash or ram selftest failed
! All error indications in the display flash once per second. The help text explains the error.
In case of cable fault the backlight also flashes. This can be reset by pressing the 3 key.
Errors affecting both channels are shown as error on channel 1 - and the line showing channel 2 is blank.
Hardware error can be reset in two ways. Either step through the menus (if the other channel is to stay in
operation) or power cycle the device.
