9202 - Product version 9202-003 17
Configuration / operating the function keys
Documentation for routing diagram.
In general
When configuring the 9202, you will be guided through all parameters and you can choose the settings which fit the
application. For each menu there is a scrolling help text which is automatically shown in line 3 on the display.
Configuration is carried out by use of the 3 function keys:
1 will increase the numerical value or choose the next parameter
2 will decrease the numerical value or choose the previous parameter
3 will save the chosen value and proceed to the next menu
When configuration is completed, the display will return to the default state 1.0. Pressing and holding 3 will return to the
previous menu or return to the default state (1.0) without saving the changed values or parameters.
If no key is activated for 1 minute, the display will return to the default state (1.0) without saving the changed values or
parameters.
Further explanations
Password protection: Programming access can be blocked by assigning a password. The password is saved in the device in
order to ensure a high degree of protection against unauthorized modifications to the configuration. If the configured
password is not known, please contact PR electronics support - www.prelectronics.com/contact.
Cable fault information via display front 45xx
Cable fault (see limits in the table) is displayed as CA.BR (cable break) or CA.SH (cable short-circuited). Cable fault is shown
independently for each channel but the configuration is common for both channels. In case of cable fault the backlight flashes.
This can be reset by pressing the 3 key. When the cable fault has been remedied, the module will return to normal operation.
Advanced functions
The unit gives access to a number of advanced functions which can be reached by answering “Yes” to the point “ADV.SET”.
Display setup: Here you can adjust the brightness contrast and the backlight. Setup of TAG numbers with 5 alphanumerics.
Selection of functional readout in line 2 and 3 of the display - choose between readout of digital output or tag no. When
selecting ”ALT” the readout toggles digital output and tag no.
Password: Here you can choose a password between 0000 and 9999 in order to protect the unit against unauthorised
modifications to the configuration. The unit is delivered default without password.
Language: In the menu ”LANG” you can choose between 7 different language versions of help texts that will appear in the
menu. You can choose between UK, DE, FR, IT, ES, SE and DK.
Power rail: In the menu ”RAIL” you can choose if errors in the module are transmitted to the central surveillance in the PR
9410 power control unit.
Safety Integrity Level (SIL): See Safety Manual for details.
