PR 3104 - DIP-Switch Configuration Details; 3105 DIP-Switch Settings; 3109 DIP-Switch Settings

3100V106-IN 19
1 2 3 4 5 6 7 8 9 10
0…20mA NA OFF OFF OFF 0…20mA OFF OFF OFF NA NA NA
4…20mA NA OFF ON OFF 4…20mA OFF ON OFF NA NA NA
0…10V NA ON OFF OFF 0…10V ON OFF OFF NA NA NA
2…10V NA ON ON OFF 2…10V ON ON OFF NA NA NA
0…5V NA ON OFF ON 0…5V ON OFF ON NA NA NA
1…5V NA ON ON ON 1…5V ON ON ON NA NA NA
1 2 3 4 5 6 7 8 9 10
0…20mA OFF OFF OFF OFF 0…20mA OFF OFF OFF OFF OFF OFF
4…20mA OFF OFF ON OFF 4…20mA OFF ON OFF OFF ON OFF
0…10V OFF ON OFF OFF 0…10V ON OFF OFF ON OFF OFF
2…10V OFF ON ON OFF 2…10V ON ON OFF ON ON OFF
0…5V OFF ON OFF ON 0…5V ON OFF ON ON OFF ON
1…5V OFF ON ON ON 1…5V ON ON ON ON ON ON
0...20 mA Tx ON OFF OFF OFF
4...20 mA Tx ON OFF ON OFF
3105
Input setup Output setup
Input setup
Output setup
Channel 1 Channel 2
3109
