5104V104-UK 9
Electrical specifications
Specifications range:
-20°C to +60°C
Common specifications:
Supply voltage, universal ............................ 21.6...253 VAC
50...60 Hz
19.2...300 VDC
Internal consumption .................................. ≤ 2 W (2 channels)
Max. consumption....................................... ≤ 3 W (2 channels)
Fuse ............................................................. 400 mA SB / 250 VAC
Isolation voltage, test / operation ............... 3.75 kVAC / 250 VAC
Signal / noise ratio ...................................... Min. 60 dB (0...100 kHz)
Response time (0...90%, 100...10%) .......... < 25 ms
Calibration temperature............................... 20...28°C
Order: 5104
Type Version Input Output Channels
5104 Standard : A 0...20 mA : A
4…20 mA : B
0...10 V : E
2...10 V : F
Special : X
Special : 0
0...20 mA : 1
4…20 mA : 2
0...1 V : 4
0.2...1 V : 5
0...10 V : 6
2...10 V : 7
Single : A
Double : B
[EEx ia] II C
IS, DIV. 1 : B
