PR 5104 - TECHNICAL SPECIFICATIONS; Accuracy, EMC, and Immunity; Input, Output, and Auxiliary Data

10 5104V104-UK
Accuracy, the greater of the general and basic values:
Auxiliary supply:
Loop supply (pin 44...42 and 54...52) ......... 28...17.1 VDC / 0...20 mA
Max. wire size .............................................. 1 x 2.5 mm
2
stranded wire
Screw terminal torsion ................................ 0.5 Nm
Relative humidity ......................................... < 95% RH (non-cond.)
Dimensions (HxWxD) ................................... 109 x 23.5 x 130 mm
DIN rail type ................................................. DIN 46277
Protection degree ........................................ IP20
Weight ......................................................... 225 g
Current input:
Measurement range .................................... 0...20 mA
Min. measurement range (span).................. 16 mA
Max. offset................................................... 20% of max. value
Input resistance ........................................... Nom. 10 Ω + PTC 10 Ω
Voltage input:
Measurement range .................................... 0...10 VDC
Min. measurement range (span).................. 8 VDC
Max. offset................................................... 20% of max. value
Input resistance ........................................... > 2 MΩ
Current output and 2-wire 4...20 mA output:
Signal range (span) ...................................... 0...20 mA
Min. signal range (span) .............................. 16 mA
General values
Input type
Absolute
accuracy
Temperature
coefficient
All ≤ ±0.1% of span ≤ ±0.01% of span / °C
Basic values
Input type
Basic
accuracy
Temperature
coefficient
mA ≤ ±16 µA ≤ ±1.6 µA/°C
Volt ≤ ±8 mV ≤ ±0.8 mV/°C
EMC immunity influence ..................................... < ±0.1% of span
Extended EMC immunity:
NAMUR NE 21, A criterion, burst ....................... < ±1% of span
