PR 5104 - OUTPUT AND SAFETY APPROVALS; Voltage Output and I.S. Approvals; Authority Certifications

5104V104-UK 11
Max. offset................................................... 20% of max. value
Load (max.) .................................................. 20 mA / 600 Ω / 12 VDC
Load stability ............................................... ≤ 0.01% of span / 100 Ω
Current limit ................................................. ≤ 28 mA
Max. external loop supply ........................... 29 VDC
Effect of external loop supply
voltage change ............................................ < 0.005% of span / V
Voltage output:
Signal range (span) ...................................... 0...1 VDC / 0...10 VDC
Min. signal range (span) .............................. 0.8 VDC / 8 VDC
Max. offset................................................... 20% of max. value
Load (min.) ................................................... 500 kΩ
EEx / I.S. approvals:
DEMKO 99ATEX126013 .............................. II (1) GD
[EEx ia] IIC
Applicable for zone ..................................... 0, 1, 2, 20, 21 or 22
UL ................................................................ IS, Cl. I, Div. 1, Group A, B, C, D
IS, Cl. I, zone 0 og 1, Group IIC
IS, Cl. II, Div. 1, Group E, F, G
UL Control Drawing No. .......................... 5104QU01
Ex / I.S. data:
U
m
............................................................... : 250 V
U
o
................................................................ : 28 VDC
I
o
.................................................................. : 93.0 mADC
P
o
................................................................ : 0.65 W
L
o
................................................................. : 3 mH
C
o
................................................................ : 0.08 µF
Marine approval:
Det Norske Veritas, Ships & Offshore ......... Standard for Certification No. 2.4
GOST R approval:
VNIIM & VNIIFTRI, Cert. No. ....................... See www.prelectronics.com
Observed authority requirements: Standard:
EMC 2004/108/EC ...................................... EN 61326-1
LVD 2006/95/EC .......................................... EN 61010-1
PELV/SELV ................................................... IEC 364-4-41 and EN 60742
ATEX 94/9/EC .............................................. EN 50014, EN 50020 and
EN 50281-1-1
UL ................................................................ UL 913, UL 508
Of span = Of the presently selected range
