SEQUENTIAL CHARGING
Note: The time-delayed allocation of the charging current is not supported by all electric vehicles.
A charging current of at least 6A is required for each vehicle to be charged.
If the wallbox has been configured for a low charging current, this may mean that not both vehicles can be charged at the same
time. In this case, the two connected vehicles are charged one after the other (sequentially).
If the charging process of the second vehicle does not start automatically, it may be necessary to disconnect the vehicle from the
system for a short time first. After reconnection, the charging process starts.
As a precaution, observe the connection sequence to the box. First connect the vehicle that does not support sequential charging.
Only then connect the second vehicle (sequential charging is supported by this one).
RESTARTING THE BOX
To restart the box, first disconnect all vehicles from the system.
Switch off the wallbox's internal RCD for 5 seconds.
After switching on the voltage, the microcontroller of the box restarts automatically.
Within 2 seconds, the box signals the preselected setting by white flashing of the LEDs, 10 flashes signal a presetting of 10 amps.
INTERFACE RS 485
The RS 485 interface communicates with Modbus RTU, 9600 baud, 8 DATA bits, 1 stop bit, parity none, slave ID 1
Modbus
Register
Default Value
Value Type
40001
Modbus ID
1
40002
Modbus Baudrate
96
(corresponds to 9600)
40003
Max electrictiy total border
255
in A
40004
Max electrictiy KFZ1 border
255
in A
40005
Max electrictiy KFZ2 border
255
in A
30012
Assigned electrictiy KFZ1
0
in A
30013
Assigned electrictiy KFZ2
0
in A
30075
Learned RFID Card (Amount)
255
30101
Software Version RFID and Modbus
Module
255
30102
Software Version main circuit board
255
30104
Temperature in Box
255
Value temperature sensor
30105
Last command set received from the
main board
0
30106
Last data set received from the main
board
0
30107
Status Car1
255
0 no car, 1 car connected, 2 loading request, 3
loading request with fan, 4 short circuit
30108
Status Car2
255
0 no car, 1 car connected, 2 loading request, 3
loading request with fan, 4 short circuit
30115
Set charging current supply line
255
value in A
30116
Set charging current supply line after
correcting temperature and setting
255 value in A
