PRACHT ALPHA - Operation; LED Display; Charging

9
OPERATION
This charging station is suitable for electrically charging one or two vehicles with type 2 charging couplings.
Please also refer to the operating instructions for your electric vehicle.
LED-DISPLAY
The wallbox is equipped with a separate LED indicator light for each charging cable, which shows the current status during
operation.
LED-DISPLAY
DEVICE STATUS
Green
No vehicle connected, wallbox ready for operation
Blue
No vehicle connected, box locked via RFID module*.
Yellow
Vehicle connected, waiting state, charging process completed
Green, flashing slowly
Vehicle is being charged
Red, flashing repeatedly 3 times
Fault on cable, charging coupler or vehicle
Red, flashing quickly
Short circuit on cable, charging coupler or vehicle
3 seconds pink flashing
RFID card* not known / all RFID cards* successfully deleted
3 seconds white
RFID card* has been tuned in
*Depending on the version of the box, an RFID module is available. The RFID module can be retrofitted as an accessory.
The LED indicator lights also show the preset current consumption every time the box is restarted.
CHARGING
Connect your vehicle to the wallbox.
As soon as the electric vehicle is ready for charging the charging process starts automatically.
After successful charging, the vehicle ends the charging process automatically. “Overcharging" is therefore not possible.
If two vehicles are charged at the same time the wallbox regulates the available power. For example, the charging current is
divided between the two vehicles. If the charging process of one of the two vehicles is completed, the charging power of the
vehicle still charging is automatically increased.
