Main Control Board/Display
The control board signals each oven component based on commands sent from the keypad that were
selected by the operator. The display is attached to the control board and will come together if the
control board is ordered.
The board has a current sensor which measures the amp draw of the microwave circuit through the
brown CT wire looping through it. The current sensor is what determines if the microwave circuit is
working correctly by communicating the registered amp draw to the board.
