PreCise TT-3500 - Specifications

Model No. TT-3500
Page6of7
Feb 2010
SPECIFICATIONS
Model No. TT-3500 Induction Hob
Voltage 230V~50/60Hz
Vitro-ceramic Plate Approx.300mm x 300mm x 6mm thickness
Electrical Power Consumption Max. 3500 watt, 15.9A
Electrical Power Range Approx. 350 watt ~ 3500 watt
Functions  Power regulate: 19 steps, from 350w-3500w
 Temperature holding: from 50-240
o
C, every 10
o
C
Dimension 385mm X 520mm X 197mm (including the foot stand)
Remarks The switching frequency is verified by different power setting,
to be between 20~35K Hz.
1. 3500watt Induction Heating Zone
2. Vitro Ceramic Top Plate
3. Stainless Steel Housing
4. Air-Intake (Air filter)
5. Air-Outlet
6. Power On/ Off key.
7. Induction Heating Indicator Light
8. Power Control Knob (Power regulator)
9. Heat / Warm function select key
10. Heat/ Warm Indicator Light.
11. Heat/ Warm temperature "+", "-"
12. LED Power steps 1-19
1
2
5
3
7
8
11
12
6
10
9
4
