One Place Monitor Panel
5. Touching Battery Levels button brings you to this screen. The
Chassis and House Battery Voltages will display in both Digital and
Analog (bar graph) format. The Analog range is 10.0V-15.0V; with
bar graph meter increments of 0.125Volts.
The screen will continually update every 1 second.
Ch ass i s Ba t Vol tag e
13 . 2V ———
Ho use Ba t Vol tag e
12 . 6V ————
""" ""
""" "
F r e s h W a t e r T a n k 2/ 3
L . P . G a s T a n k E
G ra y W a s t e T a n k 1/3
B l a c k W a s t e T a n k F
F r e s h W a t e r T a n k 2/ 3
L . P . G a s T a n k E
G ra y 1 Wa s t e T n k 1/3
G ra y 2 Wa s t e T n k 1/3
B l a c k1 W a s t e T n k F
B l a c k 2 W a s t e T n k F
6. Pressing Tank Levels switch brings you to this screen.
The screen will continually update every 1 second.
After 1 minute Backlighting will go off, and display will return to the
Default Screen (Water Pump.) Should a sensor exceed normal limits,
ERR will display in place of the level. Depending on your RV, the
Levels will be displayed in either 1/3's or 1/4's. E, 1/3, 2/3, F, or ERR;
or E, 1/4, 1/2, 3/4, F, or ERR.
If your RV is equipped with extra Waste Tanks, then the display is
split onto two screens as shown below, and touching the Tank
Levels button toggles between the two screens.
