Retransmitting Output
OUTPUT RANGE Retransmitting: 4 to 20 mA (600 Ω maximum)
SCALING RANGE Any display range (see range for the input selected)
ACCURACY +0.1% of full scale
Serial Communications
PROTOCOLS Modbus (ASCII, RTU), PC software,
UNIT ADDRESS 1 to 99 (Max 31 units connected)
BAUD RATE 600, 1200, 2400, 4800, 9600, 19200 bps, user selectable
RESPONSE TIME 0 to 100 ms delay response time
10 ms increments user selectable
DATA 7 or 8 bit user selectable
PARITY None, even, or odd
Approvals
UL RECOGNIZED USA and Canada
Process Control Equipment
UL FILE NUMBER E244207
CE COMPLIANT
PD570 Series Nova Process and Temperature Limit Controller Instruction Manual
10
