16
PM-1030V v5 2020-10 Copyright © 2020 Quality Machine Tools, LLC
Z1 35T 40T 45T 50T
C
0.35 0.40 0.45 0.50
A 0.70 0.80 0.90 1.00
B 1.40 1.60 1.80 2.00
Not illustrated
Z2: 65T
Z3: 45T
Z4: 39T
Lower gear: 63T
C
-
A 1.75
B -
THREAD CUTTING SETUPS — Metric threads in mm pitch
C
-
A 1.25
B 2.50
C
0.75
A 1.50
B 3.00
C
0.60
A 1.20
B 2.40
Figure 3-22 Gear setups for metric threads
