27
PM-1030V v5 2020-10 Copyright © 2020 Quality Machine Tools, LLC
Dimensions in millimeters
GEARBOX Fig 3
Ref Description Part
1 Circlip Φ14 Z1086
2 Screw M5 x 10 Z1087
3 Left-hand ange Z1088
4 Ball bearing 6202 Z1089
5 Key 5 x 12 Z1090
6 Double gear assembly Z1091
7 Sleeve Z1092
8 Screw M5 x 8 Z1093
9 Rear cover Z1094
10 Body casting Z1095
11 Gear Z1096
12 Key 4 x 8 Z1097
13 Key 4 x 10 Z1098
14 Gear shaft Z1099
15 Gear Z1100
16 Circlip Z1101
17 Right-hand ange Z1102
18 Taper pin Φ4 x 22 Z1103
19 Leadscrew coupler Z1104
20 End plug Z1105
21 Triple gear assembly Z1106
22 Gear shifter crank Z1107
23 Pin Φ5x16 Z1108
24 Shifter fork Z1109
25 Hex set screw M6 x 6 Z1110
26 Shifter fork Z1111
Ref Description Part
27 Screw M6 x 45 Z1112
28 Bushing Z1113
29 Shaft Z1114
30 Circlip Z1115
31 Intermediate gear Z1116
32 End plug Z1117
33 Sliding bearing 1610 Z1118
34 Circlip Z1119
35 Gear Z1120
36 Key Z1121
37 Shaft Z1122
38 Key 4 x 50 Z1123
39 Sliding bearing 1616 Z1124
40 Front cover Z1125
41 Screw M5 x 16 Z1126
42 Shaft Z1127
43 O-ring Φ10 x 1.8 Z1128
44 Screw M3 x 6 Z1129
45 Gearbox label Z1130
46 Pin Φ5 x 26 Z1004
47 Knob Z1132
48 Steel ball Φ5 Z1133
49 Spring Φ0.8x4x14 Z1134
50 Set screw M6 x 16 Z1135
51 Pointer label Z1136
52 Sight glass Z1137
