APRON Fig 4
Ref Description Part
1 Handle bolt Z1138
2 Handle sleeve Z1139
3 Locknut M8 Z1140
4 Washer M8 Z1141
5 Handwheel Z1142
6 Graduated collar Z1143
7 Leaf spring Z1144
8 Flange Z1145
9 Screw M5 x 12 Z1146
10 Spring 1 x 16 x 20 Z1147
11 Shifter shaft Z1148
12 Feed selector gear Z1149
13 Set screw M5 x 6 Z1150
14 Roll pin Φ4 x 20 Z1151
15 Flange Z1152
16 Key 4 x 4 x 10 Z1153
17 Key 4 x 4 x 12 Z1154
18 Gear shaft Z1155
19 Set screw M5 x 8 Z1156
20 Gear 60T Z1157
21 Gear 23T Z1158
22 Oil plug M16 x 12 Z1159
23 Apron body Z1160
24 Gear 53T Z1002
25 Roll pin Φ4 x 20 Z1003
26 Gear shaft Z1001
27 Screw M5 x 35 Z1164
28 Taper pin Φ5 x 28 Z1165
29 Worm support block Z1166
30 Circlip Φ12 Z1167
31 Worm gear 17T Z1000
32 Int. keyed worm Z1169
33 Key 4 x 4 x 12 Z1170
34 Worm gear shaft Z1171
35 Set screw, coned M4 x 8 Z1172
36 Collar Z1173
Ref Description Part
37 Roll pin Φ4 x 20 Z1174
38 Gear 34T Z1175
39 Cam shaft Z1176
40 Pin 8 x 24 Z1177
41 Half nut Z1178
42 Half nut support Z1179
43 Screw M5 x 30 Z1180
44 Set screw, coned M4 x 8 Z1181
45 Roll pin Φ4 x 20 Z1182
46 Bushing Z1183
47 Steel ball Φ5 Z1184
48 Spring 0.8 x 4 x 14 Z1185
49 Set screw M6 x 6 Z1186
50 Sight glass Z1187
51 Roll pin Φ4 x 25 Z1188
52 Flange Z1189
53 Flange Z1190
54 Screw M5 x 12 Z1191
55 Roll pin Φ5 x 40 Z1192
56 Half nut lever hub Z1193
57 Roll pin Φ4 x 28 Z1194
58 Feed lever hub Z1195
59 Lever Z1196
60 Label Z1197
61 Screw M3 x 6 Z1198
62 Screw M5 x 35 Z1199
63 Feed selector base Z1200
64 Selector sleeve Z1201
65 Shaft Z1202
66 Spacer bushing Z1203
67 Idler gear 20T Z1204
68 Shaft Z1205
69 Locking wheel Z1206
70 Shaft Z1207
71 Set screw, coned M4 x 8 Z1208
72 Set screw M6 x 6 Z1209
