Precision matthews PM-25MV - Head Components Parts List

21
PM 25MV v9 2021-12 Copyright © 2021 Quality Machine Tools, LLC
Dimensions in millimeters
Ref Description Part
1 Spindle Z5209
2 Bearing seal Z5210
3 Roller bearing 32007 Z5211
4 Quill sleeve Z5212
5 Roller bearing 32005 Z5213
6 Spacer Z5214
7 Washer, nitrile Z5215
9 Screw: M5 x 12 skt hd Z5217
10 Quill lock handle Z5218
11 Casting plug Z5219
12 Quill guide pin Z5220
13 Headstock Z5221
14 Nut: M3 Z5222
15 Screw: M3 x 8 pan hd Z5223
16 DRO bracket Z5224
17 Screw: M4 x 10 pan hd Z5225
18 Washer: at, M4 Z5226
19 Screw: M4 x 6 pan hd Z5227
20 Washer: at, M4, large Z5228
21 DRO back plate Z5229
22 DRO assembly Z5230
23 Screw: M4 x 55 pan hd Z5231
24 DRO connector block Z5232
25 Fine feed knob Z5233
26 Screw: M5 x 8, set Z5234
27 Leaf spring Z5235
28 Graduated dial, ne Z5236
29 Worm spindle Z5237
30 Pin: taper, 8 x 30 Z5238
31 Graduated dial, coarse Z5239
32 Coarse feed hub Z5240
33 Coarse feed handle Z5241
34 Coarse feed spoke Z5242
35 Clamp knob Z5243
36 Screw: M4 x 10 skt hd Z5244
37 Compression spring Z5245
38 Pinion shaft ange Z5246
Ref Description Part
39 Sleeve Z5247
40 Worm gear Z5248
41 Pinion shaft Z5249
42 Key: 4 x 12 Z5250
43 Screw: M6 x 12, set Z5251
44 Pin: 5 x 10 Z5252
45 Retaining ring: 45, ext Z5253
46 2-step spindle pulley Z5254
47 Screw: M6 x 8, set Z5255
48 Screw: M6 x 6, set Z5256
49 Return spring cup Z5257
50 C-clip, spring retainer Z5258
51 Drawbar cap Z5259
52 Drawbar cover Z5260
53 Ball bearing: 6209 Z5261
54 Spring, quill return Z5262
55 Screw: M6 x 8, cone pt Z5263
56 Tach sensor coil Z5264
57 Splined sleeve Z5265
58 Key: 6 x 25 Z5266
59 Ball bearing: 6007-2Z Z5267
60 Motor cover Z5268
61 Washer: at, M4 Z5269
62 Screw: M4 x 10 pan hd Z5270
63 Motor, DC ,Main Motor Z5271
64 Screw: M5 x 20 skt hd Z5272
65 Washer: at, M5 Z5273
66 Key: 6 x 16 Z5274
67 Screw: M8 x 30 skt hd Z5275
68 Washer: at, M8 Z5276
69 Motor mount, lower Z5277
70 2-step motor pulley Z5278
71 Screw: M6 x 20 skt hd Z5279
72 Motor mount, upper Z5280
73 Bushing Z5281
76 Ribbed belt Z5284
HEAD COMPONENTS Fig 2
