Note-When the Emergency Stop is activated a “Safety Circuit Error” will be returned to the User
Interface.
4.4 Shelf-Switch
Note-This section only applies if Motorized Shelf or Programmable Shelf option is installed. Refer
to section 7.6 Motorized Shelf and 7.7 Programmable Shelf for more details
The Shelf-Switch will move the Motorized/Programmable Shelf within the cabinet up and down to
adjust the source to specimen distance (SSD). Turning the switch counterclockwise will lower the shelf
while clockwise will raise the shelf.
Note-If Programmable Shelf option is installed, the Shelf-Switch will only work while the
TouchRAD User Interface is in Program Mode or Manual Mode
4.5 Touchscreen Computer
The touchscreen computer hosts the TouchRAD User Interface. This computer can only be turned on
and off via the System Key-Switch. When the System is initially put in STANDBY mode, the computer
will turn on and take about 30 seconds before the TouchRAD User Interface starts up. When the System
is initially put in OFF mode, the computer will immediately start to shut down and take about 30
seconds before it is completely off. In order for proper ON/OFF cycles of the computer to occur, the
System must remain in OFF state for at least 30 seconds before it can be put back in STANDBY state.
4.6 USB Port
The USB Port is to be used by the User for downloading the System Database and plugging in an
external WIFI adaptor for use with PXi’s Remote Access feature.
5 TouchRAD User Interface
5.1 Overview
The TouchRAD User Interface is a touchscreen based application from which all functionality of the X-
RAD system is controlled. It enables users to run exposures, set exposure routines, administer user
accounts and much more.
5.2 System Startup
Note-Precision X-Ray highly recommends that the system be warmed-up weekly, regardless of
system usage.
