Commercial Treadmill Assembly Guide 2
Hardware Kit (not shown to scale)
Fasteners Quantity
(A) Buttonhead screw (1-inch) 12
(B) Washer (stainless steel) 16
(C)Socket head screw (3¹⁄₂-inch)
4
(D) Flat head hex screw (1-inch) 4
(E) Washer (stainless steel) 4
