40 Assembling and Maintaining TRM 800-Series Treadmills
Table 2. P80 internal cable connections
Cable Connector Type Circuit Connector
Location
Ethernet (LAN) Eight-contact modular, on
round black cable
TV in F-type coaxial
Power Two-contact plug,
polarized and latched
Data from base
unit
Eight-contact modular, on
flat gray cable
Heart rate sensors Four-contact strip, keyed
Safety key
(treadmills only)
Six-contact strip, keyed
CSAFE Eight-contact modular, on
flat gray cable
To simplify installation and maintenance, route and connect
cables 1 through 5 according to the following instructions.
Note: In the illustrations in this section, some cables are
omitted for the sake of clarity.
