General Information
The following information provides general equipment and service information that will help
you to use this manual to properly repair and maintain the bike.
Orientation Convention
The equipment orientation (front, right, left, back) used in manual is referenced to a user sitting
on the equipment facing the handlebars.
Tools
Recommended set of service and repair tools:
l Metric Hex Key set (2.5 - 6mm) l Torque wrench 40 ft-lbs (54 N•m
l Metric Wrench set (10 - 21mm) l Crank Extractor (Part:X-Tools Crank Extractor)
(1)
l Screw driver set ) l Belt Tension Gauge (recommended Kent-Moore BT-33-
73-F)
Note: (1) Required for pedal removal.
Specification Summary
This table provides a summary of system component specifications.
System Component Specification
Pedal Torque 33 ft-lb (45 N•m)
