System Component Specification
Belt Drive Tension 140 - 150 lbs
Chain Drive Tension 1/2 in (1.3 cm) up/dwn travel
Stabilizer fastener Torque 15.6 ft-lbs (21 N•m)
Axle Nut Torque 29.5 ft-lbs (40 Nm)
.
Parts
IMPORTANT: Always purchase OEM replacement parts and hardware from Precor.
If you use parts not approved by Precor, you could void the Precor Limited Warranty.
Use of parts not approved by Precor may cause injury.
Major Assembly and Parts Location
Exploded View Diagram and Parts List
There is a copy of the parts
Exploded View Diagram
and
Parts Identification List
included in
the "Parts" on page68 chapter that you can use as a quick reference. It is recommended that
you go to the servicer partners Precor Connect website to view the most current parts
information including the
Exploded View Diagram
and
Parts Identification List
.
Page 4
1 Introduction
General Information
