Page 2 K&(%$*4.8"4,7%R'*#$"&8#J%/7*,#*%4,77%PSTTTSTQQSUVWV1 ITEM 69727
E,+7*%&2%<&8$*8$#
Specifications ............................................. 2
Safety ......................................................... 3
Setup .......................................................... 6
Operation .................................................... 8
Maintenance .............................................. 12
Troubleshooting ......................................... 16
Warranties ................................................. 18
Parts Lists and Diagrams .......................... 20
F/*4"2"4,$"&8#
Displacement 212cc
Engine Type
Horizontal Single Cylinder
4-stroke OHV
Meets EPA phase III and CARB
emissions standards
Cooling System Forced air cooled
Fuel
Type
87+ octane stabilizer-treated
unleaded gasoline
Capacity 0.9 Gallon
Engine Oil
Type SAE
10W-30 above 32° F
5W30 at 32° F or below
Capacity 0.5 Quart
Run Time @ 50% Load
with full tank
3 hr.
Sound Level at 22 feet 104 dB
Bore x Stroke 70 mm x 55 mm
Compression Ratio 8.5:1
Rotation viewed from PTO
(power takeoff - the output shaft)
Counterclockwise
Spark Plug
Type
NGK
®
BP-6ES
NHSP
®
/ Torch
®
F6TC
Gap 0.027" - 0.031"
Valve Clearance
Intake 0.004" - 0.006"
Exhaust 0.006" - 0.008"
Speed Idle 1,800± 50 RPM
Shaft
Shaft Ø0.75″ x 2.43″
Keyway 3/16″
End Tapped 5/16″ - 24 UNF
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency and by the California Air Resources Board (also known as CARB).
For warranty information, refer to the last pages of this manual.
