Predator 62214 - Parts Lists and Diagrams

Page 24 For equipment technical questions, please call 1-888-866-5797. ITEM 62214
SAFETY SETUP OPERATION MAINTENANCE
Parts Lists and Diagrams
General Parts List
Part Description Qty.
1 Wand 1
2 Spray Gun 1
3 Spray Gun Holder 1
4 Knob 2
5 Handle 1
6 Handle Grip 1
7 Hose Hanger 1
8-1 Red Nozzle – 0° 1
8-2 Yellow Nozzle – 15° 1
8-3 Green Nozzle – 25° 1
8-4 White Nozzle – 40° 1
8-5 Black Nozzle – Detergent 1
9 Nozzle Grommet 5
10 Bolt 4
11 Nozzle Panel 1
12 Handle Knob 2
13 Frame 1
14 Wand Holder 2
15 Pressure Hose 1
Part Description Qty.
16 Flange Nut 4
17 Engine Mounting Bolt 4
18 Flange Nut 4
19 Pin 2
20 Bolt 2
21 Washer 4
22 Axle 2
23 Detergent Tank Lid 1
24 Detergent Tank 1
25 Bolt 1
26 Rubber Pad 1
27 Gasket 1
28 Wheel 2
29 Engine 1
30 Key 1
31 Bolt 4
32 Pump 1
33 Detergent Tube 1
34 Bolt 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
