Page 26 For equipment technical questions, please call 1-888-866-5797. ITEM 62214
SAFETY SETUP OPERATION MAINTENANCE
Pump Parts List
Part Description Qty.
1A Head Bolt M8 x 45 3
2A Pump Head 1
6A Plug 1
7A O-Ring Ø7.66 x 1.78 1
8A Plug - Aluminum 3
9A O-Ring Ø14 x 1.7 4
10A Check Valve 6
11A O-Ring Ø9 x 1 1
12A Seat 1
13A By-Pass Jet 1
14A O-Ring Ø10.82 x 1.78 1
15A Piston Guide 1
16A Ring 1
17A O-Ring Ø6.07 x 1.78 1
18A O-Ring Ø6.02 x 2.62 1
19A Piston 1
20A Nut M6 1
21A Grub Screw M6 x 16 1
22A Handle Insert 1
23A Plate Spring 2
24A Spring 1
25A Gasket 6
26A O-Ring Ø23.52 x 1.78 3
27A Bushing 3
28A Bushing 3
29A Oil Seal 3
30A Housing 1
Part Description Qty.
31A O-Ring Ø6.75 x 1.78 1
32A Oil Plug 1
33A O-Ring Ø4.48 x 1.78 2
34A Hose Nipple 1
35A Ball 1
36A Spring 1
37A O-Ring Ø4 x 2.5 1
38A Jet 1
39A Spring 1
40A O-Ring Ø8.73 x 1.78 2
41A Detergent Injector 1
42A Inlet Fitting 3/4" NH 1
43A Suction Fitting 1
44A Filter 1
46A Outlet Fitting 1
48A Spring 3
49A Piston 3
50A Ring 3
51A Thrust Washer 1
52A Bushing 1
53A Thrust Washer 1
54A Hollow Shaft 1
55A Bearing 1
56A Circlip Øi72 1
57A Seal 1
58A O-Ring Ø14 x 2 2
When ordering replacement parts from this list, the “A” suffix must be included in order to get the correct part.
